CMM-1.0LT Transformer Oil Purification Unit

The CMM-1.0LT unit is designed for thermo-vacuum drying and filtration of industrial oils used in lubrication, sealing, and hydraulic control systems of gas turbines, gas compression units, gas piston compressors, as well as transformers. In addition to oil purification, the unit can be used for heating and drying oil-filled electrical equipment. Under vacuum, the oil passes through a coarse filter with a filtration rating of 200 μm, then enters a vacuum tank with a built-in heater. The heated oil is distributed over special fillers, where moisture and gases are efficiently removed under vacuum. The oil is then pumped from the bottom of the tank through two fine filters with selectable ratings of 5, 3, 1, or 0.3 μm and delivered to the outlet. The placement of the heater inside the vacuum chamber and the optimized layout ensure compact unit dimensions and reduced heat loss.

Request Price

Description
Specification
Advantages
Application
Configurator
Payback period
Webinar
Video
Gallery
Publications

СММ-1.0LT unit is designed for thermal vacuum drying and filtration of industrial oils used in lubrication, sealing, hydraulic control systems of gas turbine and gas pumping units, gas engine compressors, and in transformers. In addition to oil purification, CMM-1.0LT may be used for heating and drying the oil-filled electrical devices.

Principle of operation

The oil driven by vacuum passes through a coarse filter with the filtration fineness of 200 microns after which it gets inside a vacuum tank where a heater is located. Rising from bottom to top, the oil heats up and gets into the other part of the chamber through a special channeled lid coming directly to special fillers. Next, the oil flows down the fillers, while the moisture vapor and gases are removed from the oil by vacuum. Then, the oil is pumped out from the tank bottom through two fine filters to the unit outlet. The filtration fineness of the filters can be selected at 5, 3, 1, or 0.3 microns.

Design features

The heater is located inside the vacuum tank which made it possible to reduce the unit dimensions and to diminish the heat losses while heating the oil.

The oil is sucked into the vacuum chamber due to the underpressure generated by a vacuum system. A new layout has been applied to the rest of the unit components. All of these innovations have yielded good results in terms of small equipment dimensions.

Parameter		Value
1. Capacity, m³/h (gpm), not less than
	– in the thermal vacuum drying and filtration mode	1.0 (4,4)
2.* Processed oil parameters (in several passes):
	– total gas content, %, not more than	1,5
	– oil moisture mass content, ppm, not more than	10 ppm or 5 ppm or 5 ppm+ (optionally)
	– industrial purity class of ISO 4406	-/14/12
3. Max output oil temperature, ºС (ºF)		55 (131)
4. Output pressure, bar (psi)		3 (43,5)
5. Oil heater power, kW, not more than		12
6. Max power requirement, kW, not more than		15
7. Electric current parameters
	– voltage, V	380
	– AC with frequency, Hz	50
	– number of phases	3
8. Dimensions, mm (in), not more than (w/o trailer/with trailer)
	– length	910 (36)/2450 (96)
	– width	620 (24)/1420 (56)
	– height	1500 (59)/1910 (75)
9. Weight, kg, not more than (w/o trailer/with trailer)		280 (617)/730 (1600)

Note:

* At initial parameters of oil:

volumetric gas content — not more than 10.5%;
moisture mass content — not more than 0.005% (50 ppm);
temperature — not lower than 0ºС (32ºF)
when the oil passes through the unit multiple times.

сompactness;
mobility;
ease of control;
used to purify industrial oils of various types: turbine, hydraulic, compressor, etc.

Application:

Unit’s total working hours per day, hour

Hourly rate of the unit’s service engineer

kWh cost in your region

Cost of one filter for replacement in your region (fineness of filtration — 5 microns)

Filtration cost of 1 m3 of oil made by other contractor

Delivery cost for 1 m3 of oil to the contractor for filtration services

Amount of purified transformer oil per hour, m3/hour

Кількість використання фільтрів в рік

Choose Model CMM-LT

CMM-0,6L

CMM-1.0LT

CMM-2,2LT

CMM-4.0LT

Intermediate parameters

kWh cost consumed by the unit for 1 hour of operation

Annual working hours of the unit, hour

Production cost of 1 working hour

Production cost for filtration of 1 m3 of oil by the contractor

Savings (difference between production cost from the contractor and your production cost of filtation with GC unit)

Required amount of oil to return investments for the unit, m3

Total amount of oil purified by the unit during 1 working day, m3

Payback period for the unit, days
